Five people Viewing Biological Microscope

Product Technical Parameters：
1. Optical path system: Adopting an excellent infinite distance correction optical path system;

2. Function expansion: Infinite distance correction optical system, with a focal length of 45mm according to international standards; Research grade microscope host, which can be expanded and upgraded with functions such as fluorescence, dark field, polarization, and multi person viewing in the later stage;

3. Eyepiece observation tube: a hinged wide field of view three lens tube with a tilt angle of 30 °, adjustable pupillary distance of 50-75mm, and three levels of visual/digital spectral ratios: 100/0, 20/80, 0/100, which can meet different usage needs and support eyepieces with a field of view of 25mm or more;

4. Eyepiece: WF10X/25mm, wide field eyepiece, with a field of view of 25mm and adjustable refractive;

5. Objective lens converter: an inward tilting five hole coded objective lens turntable, with comfortable rotation, accurate and reliable positioning, and an upgrade slot that can be upgraded in the later stage to achieve functions such as polarization and dark field observation; It can be connected to specific software and cameras to save objective lens information, and automatically calibrate the ruler with objective conversion;
6. Objective lens: Infinite far-field  semiapochromatic objective lens, with a flat field field of view ≥ 25mm; Adopting multi-layer coating technology ensures the sharpness, clarity, and color reproduction of images, providing high-quality and high-performance solutions for digital imaging:
4X /N.A. 0.13， W.D: 17.15; 10X /N.A. 0.30，W.D: 7.68;
20X /N.A. 0.50； WD：1.96）; 40X /N.A. 0.75，W.D: 0.78;
100X /N.A. 1.30，W.D: 0.15 oil;
7. Stage: High wear resistant ceramic coated stage with coaxial drive knob in the low position of the right hand, stroke: 80mm × 50mm, 1mm/grid, accuracy 0.1mm;
8. Focusing system: The vertical movement distance of the stage shall not be less than 25mm, with a focusing coarse adjustment upper limit stop position, adjustable coarse adjustment knob torque, and a minimum fine adjustment scale unit of ≤ 1 micron;
9. Transmitting light illumination device: Built in transmitting light Kohler illumination device, long-lasting white LED light source, with a lifespan of ≥ 20000 hours. Equipped with light intensity management (LIM) function, it can automatically adjust the brightness according to the preset light intensity when switching between different objectives;
10. Spotlight: Abbe spotlight, N.A. ≥ 1.1, adjustable gear rack, adjustable height, aperture light bar with scale markings;
11. Five people view attachment: with teaching pointers, it can realize five person preview;
12. Camera interface: The large target camera use 1XC interface, which is compatible with large chip cameras with target surfaces of ≥ 2/3 inches;
13. Image acquisition system: 12.5 million high pixel color camera, real physical resolution: 4088 * 3072, large target surface 1 "color chip, pixel size: 3.1 um * 3.1 um, maximum resolution of 4088 * 3072, maximum frame rate can reach 15 FPS, 64 Mb image cache, effective gain: 1X-32X, spectral response: 380-1100 nm, USB 3.0 B-type interface;

14. Imaging software: With software copyright. This software integrates main functions of image processing software ,dynamic image acquisition and processing as well as static image processing, and has strong operability in fluorescence synthesis and processing, dynamic image measurement, and color correction. This software system can capture dynamic images in multiple formats and with various duration schemes, real-time shooting, timed shooting, real-time shooting and recording. It is also compatible with other cameras through the Directshow interface. The functional modules include eight modules: image processing, color control, fluorescence processing, histogram, image settings, static image processing, and measurement. They can set parameters, measure and draw for static and dynamic images and support multi-faceted image processing.

Configuration List:
Microscope host, 1 unit;
Three eye observation tube, 1 piece;
Eyepiece 10X/25mm, 2 pieces;
Multi functional right-handed operating stage, 1 piece;
High numerical aperture spotlight, 1 piece;
Semi apochromatic objective lenses 4X/10X/20X/40X/100X, 1 set;
Microscope camera MSX2, 1 unit;
Digital Measurement and Analysis System, 1 set;
LED transmission lighting system, 1 unit;
Five people review attachment, 1 set.
